In the previous article thelivingchristmascompany.com guided you to use Mitsubishi HMI to monitor and control Omron E5CC Controller through “Modbus RTU”, today thelivingchristmascompany.com will continue to guide you to connect to a controller other temperature is Autonics TK4S.

The model HMI thelivingchristmascompany.com uses is GOT2000 GT2505-VTBD with built-in RS422/485 port, and for Autonics TK4S we need to choose a Model that also has an RS485 port (project use model: TK4S-T4SN)

HMI GT2505-VTBD & Autonics TK4S “Wiring Diagram”

Note: Use a 100 to120 (Ω) terminal resistor if the communication distance is long

Autonics TK4S “Modbus RTU” Parameters Setting

Here are the Modbus communication parameters that we need to set for Autonics TK4S Controller

TK4S Modbus Registers Address

>>> Temperature Settings Address = 400001 (dec)

>>> Temperature Monitoring Address = 301001 (dec)

Mitsubishi GOT2000 Modbus Configuration

How have we set up the Modbus communication parameters for Autonics TK4S, set the same for Mitsubishi GT2505 so they can be connected.

HMI “Modbus RTU” Example

+ Control Panel Design

+ TK4S No.1 Set Temperature Command

+ TK4S No.2 Set Temperature Command

+ TK4S No.1 Temperature Present Read

+ TK4S No.2 Temperature Present Read

Project Video Tutorial

======

Related Software and Documents

+ Download GT-Designer 3 Mitsubishi Software

Password Extract: thelivingchristmascompany.com

If in the process of using HMI Mitsubishi GT2505-VTBD to connect to Autonics TK4S control, you need any support, please comment below the article, thelivingchristmascompany.com will reply to you as soon as possible.
